API - AffanPay

Token

Every request to the AffanPay API must carry a token in its Authorization header. You generate that token from your AffanPay account.

How to get your token

Log in to your AffanPay account.
Go to Settings → Developer.
Under API tokens, give the token a name — for example Production store — then click Generate token.
Copy it straight away. The token is shown once and cannot be retrieved again.

POST Create Bill https://app.affanpay.my/api/v1/bill

This API is used to create a bill. The generated bill can be directly used to initiate and receive payment collections.

Authorization

Token : generated from Settings → Developer

Request header

Accept: application/json

Parameter

Type

Description

category

string

(Optional) Category ID for the bill. This can be obtained in the Category section after logging into your account.

name

string

(Required) The name or title of the bill.

description

string

(Optional) A short description of the bill (maximum 200 characters).

html

string

(Optional) HTML content for the bill’s description. Must contain valid HTML tags.

amount

decimal

(Required) The total amount for the bill. Accepts up to 2 decimal places. Minimum value is 5.00.

fee_charge_payer

boolean

(Optional) Indicates whether the payer will bear the transaction fee. Value true/false

redirect_url

string

(Optional) URL to redirect the customer after payment completion.

callback_url

string

(Optional) Endpoint to receive asynchronous payment status updates (webhook).

external_ref

string

(Required) External reference or unique identifier for the bill in your system.

customer_name

string

(Required) Full name of the customer. Maximum 60 characters.

customer_email

(Required) Customer’s email address. Maximum 50 characters.

customer_phone

string

(Optional) Customer’s phone number. Maximum 20 characters.

source

(Optional) Source identifier for the bill creation. Maximum 40 characters.

expiry_date

string

(Optional) Expiry date of the bill. Must be today or later. Format: YYYY-MM-DD HH:MM:SS.

Example Code


    <?php

    $curl = curl_init();

    curl_setopt_array($curl, array(
        CURLOPT_URL => 'https://app.affanpay.my/api/v1/bill',
        CURLOPT_RETURNTRANSFER => true,
        CURLOPT_ENCODING => '',
        CURLOPT_MAXREDIRS => 10,
        CURLOPT_TIMEOUT => 0,
        CURLOPT_FOLLOWLOCATION => true,
        CURLOPT_HTTP_VERSION => CURL_HTTP_VERSION_1_1,
        CURLOPT_CUSTOMREQUEST => 'POST',
        CURLOPT_POSTFIELDS =>'{
            "name": "",
            "amount": "",
            "customer_name": "",
            "customer_email": ""
        }',
        CURLOPT_HTTPHEADER => array(
            'Accept: application/json',
            'Content-Type: application/json',
            'Authorization: Bearer [token from Settings > Developer]'
        ),
    ));

    $response = curl_exec($curl);

    curl_close($curl);
    echo $response;

Example Response


    {
        "success": true,
        "id": "pujsSUNLeIYo",
        "url": "https://app.affanpay.my/pujsSUNLeIYo"
    }

GET Requery Payment https://app.affanpay.my/api/v1/requery?query=value

AffanPay sends a payment status callback to your system for every transaction, whether successful or not. However, in some cases, the callback may fail or not be received as intended. This API allows you to query the latest status of a payment transaction directly from AffanPay’s system.

Authorization

Token : generated from Settings → Developer

Request header

Accept: application/json

Query param

To customise the request, you can append query parameters to the endpoint URL. Two types of parameters are supported but only one can be used at a time.

Parameter

Description

bill_id

The unique identifier of the bill used to retrieve its details and related payment records.

e.g: bill_id=wxUyT47ko3v

payment_ref

The reference number of the payment used to retrieve its transaction details.

e.g: payment_ref=AP01384088585413050521

Example Code


    <?php

    $curl = curl_init();

    curl_setopt_array($curl, array(
        CURLOPT_URL => 'https://app.affanpay.my/api/v1/requery?bill_id=wxUyT47ko3v',
        CURLOPT_RETURNTRANSFER => true,
        CURLOPT_ENCODING => '',
        CURLOPT_MAXREDIRS => 10,
        CURLOPT_TIMEOUT => 0,
        CURLOPT_FOLLOWLOCATION => true,
        CURLOPT_HTTP_VERSION => CURL_HTTP_VERSION_1_1,
        CURLOPT_CUSTOMREQUEST => 'GET',
        CURLOPT_HTTPHEADER => array(
            'Accept: application/json',
            'Authorization: Bearer [token from Settings > Developer]'
        ),
    ));

    $response = curl_exec($curl);

    curl_close($curl);
    echo $response;

Example Response


    {
        "data": {
            "id": "wxUyT47ko3v",
            "name": "Multi open amount",
            "payments": [
                {
                    "payment_ref": "AP01384263015313050521",
                    "status_code": 4,
                    "status": "No Action",
                    "nett_amount": " 0.00",
                    "payment_channel": null
                },
                {
                    "payment_ref": "AP01384355115313050521",
                    "status_code": 3,
                    "status": "Failed",
                    "nett_amount": " 0.00",
                    "payment_channel": "fpx"
                },
                {
                    "payment_ref": "AP01384088585413050521",
                    "status_code": 1,
                    "status": "Success",
                    "nett_amount": " 31.20",
                    "payment_channel": "fpx"
                }
            ]
        }
    }

POST Callback to your callback_url

When a payment reaches a final state, AffanPay sends a POST request to the callback_url you supplied when creating the bill. This is how your system learns that an order has been paid.

When a callback is sent

Only for a SUCCESS or a FAILED payment — pending and no-action payments never trigger one. Each payment is sent TWICE, roughly 5 and 10 seconds apart, so your handler must be safe to run more than once. Nothing is sent if the bill has no callback_url.

Request headers we send

Content-Type: application/json

X-AFFANPAY-TIMESTAMP: 1756684800

X-AFFANPAY-HMAC: f10f01be8675bfaa…

What we expect back

Answer HTTP 200 once you have processed the callback. The body is not read. Any status of 400 or above is treated as a failure and recorded against the transaction.

Body (json)

{
    "payment_ref": "AP01384355115313050521",
    "status_code": 1,
    "status": "Success",
    "paid_amount": "324.76",
    "payer": {
        "name": "Ahmad bin Ali",
        "phone": "0123456789",
        "email": "ahmad@example.my"
    },
    "payment_channel": "fpx",
    "bank_reference": "2609011012340000",
    "bank_response_datetime": "2026-09-01 10:12:34",
    "bill": {
        "id": "k3jh2x",
        "name": "Invoice 12/2026",
        "amount": "320.75",
        "external_ref": "ORDER-1001",
        "created_at": "2026-09-01 09:00:00"
    }
}

Fields

Field	Description
payment_ref	Our transaction reference. Unique per payment attempt — use it as your idempotency key.
status_code	1 Success · 3 Failed. (2 Pending and 4 No Action exist but never trigger a callback.) Decide from this field, never from status.
status	Human-readable label for the code above. For display only.
paid_amount	What the payer actually paid. If the bill passes the service charge to the payer this is higher than bill.amount. Cast it before comparing — do not compare it as a string.
payer	Name, phone and email as entered by the payer. Any of them can be null.
payment_channel	The channel used, e.g. fpx, duitnow_qr, grabpay. Can be null.
bank_reference	Reference returned by the bank or wallet. Can be null.
bill.id	The bill code, the same value that appears in the payment page URL.
bill.amount	The amount the bill was created for, before any service charge.
bill.external_ref	Your own reference, exactly as you sent it when creating the bill. null if you did not send one.

Verifying the signature

Every callback carries an X-AFFANPAY-HMAC header so you can prove the request came from us and not from someone who guessed your callback URL. Verifying is optional — an integration that ignores these headers keeps working exactly as before — but it is strongly recommended, because your callback URL is reachable by anyone.

Where to find your secret key

Log in and open Settings → Developer. The key is shown there. It is never sent to you in a callback and it must stay on your server: anyone holding it can forge a callback that looks like ours.

The signature is a lowercase hex SHA-256 HMAC of timestamp + "." + raw request body, keyed with your secret.

Hash the RAW body

Read the body exactly as it arrives (php://input in PHP, express.raw in Node). Decoding the JSON and re-encoding it produces a different string, and the signature will then never match.

$secret    = 'YOUR_SECRET_KEY';           // Settings -> Developer
$body      = file_get_contents('php://input');
$timestamp = $_SERVER['HTTP_X_AFFANPAY_TIMESTAMP'] ?? '';
$received  = $_SERVER['HTTP_X_AFFANPAY_HMAC'] ?? '';

$expected = hash_hmac('sha256', $timestamp . '.' . $body, $secret);

// hash_equals, not ===, so a wrong signature cannot be found by timing
if (!hash_equals($expected, $received)) {
    http_response_code(400);
    exit('invalid signature');
}

// reject a callback that was captured and replayed later
if (abs(time() - (int) $timestamp) > 300) {
    http_response_code(400);
    exit('stale callback');
}

$payload = json_decode($body, true);

if ((int) $payload['status_code'] === 1) {
    // mark your order paid here - safely, this may run twice
}

http_response_code(200);

Answer 200 only when you mean it

A 200 tells us the callback was delivered and processed. If your handler crashes but your server still returns 200, we record the callback as successful and you will never be told. Return a 4xx or 5xx when processing fails so the delivery is retried and flagged.
